The single cylinder dryer for blue charcoal is a device specifically designed for drying blue charcoal. Its working principle and structural characteristics are as follows:

Working principle

The Lan Charcoal single cylinder dryer is mainly composed of an inclined rotating cylinder. Wet orchid charcoal is added from the higher end of the cylinder, while a heat carrier (such as hot air or flue gas) enters from the lower end and comes into counter current contact with the material. As the cylinder rotates, the wet material moves forward inside the cylinder, directly or indirectly receiving heat from the heat carrier, thereby achieving drying. The dried orchid charcoal is sent out from the discharge end through a belt conveyor or screw conveyor.

Structural composition

The main components of the Lan Charcoal single cylinder dryer include the cylinder body, lifting plate, small gear, motor, reducer, gear, idler roller, stop roller, feed chute, hot air duct, furnace body, etc. Its structural design is reasonable, the internal structure is scientific, the degree of automation is high, and it is easy to install, operate, and maintain. The copying plate on the inner wall of the cylinder is used to pick up and sprinkle the material, increase the contact area between the material and the airflow, improve the drying rate, and promote the advancement of the material.

Application scenarios

Lantan single cylinder dryer is widely used in metallurgy, electrical, chemical and other fields. Due to its simple structure, low failure rate, low cost, and high drying efficiency, it is particularly suitable for large-scale production and use.
